Alloy 625

Alloy 625 is a Nickel-Chromium alloy used for its high strength, excellent fabricability and outstanding corrosion resistance.

Service temperatures range from cryogenic to 1800° F. Alloy 625 strength is derived from the stiffening effect of molybdenum and columbium on its Nickel-Chromium matrix; thus precipitationhardening treatments are not required. This combination of elements also is responsible for superior resistance to a wide range of corrosive environments of unusual severity as well as to high-temperature effects such as oxidation and carburization.

AVAILABILITY SPECS
FLANGES 1/2" - 8" B444, B564, B16.5
FORGINGS B564
TENSILE REQUIREMENTS
TENSILE STRENGTH (KSI) 120 - 150
YIELD STRENGTH (KSI) 60 - 95
ELONGATION 30% MIN.

Alloy 600, also known as Inconel 600, is a nickel-chromium alloy renowned for its excellent resistance to oxidation and corrosion, particularly at high temperatures. With a composition that includes nickel, chromium, and iron, Alloy 600 is versatile and used in a variety of challenging environments where resistance to heat and corrosion is essential.

Design Features

  • Outstanding resistance to pitting, crevice corrosion, impingement corrosion and intergranular attack.
  • Almost complete freedom from Chlorideinduced stress corrosion cracking.
  • Good resistance to mineral acids, such as nitric, phosphoric, sulphuric and hydrochloric acids.
  • Good resistance to alkalis and organic acids.
  • Good mechanical properties.

Typical Applications

  • Used for structures in contact with seawater and subject to high mechanical stresses
  • Flue gas scrubbers components
  • Chimney linings
  • Superphosphoric acid production equipment
  • Sour gas production tubes
  • Offshore industry, marine equipment
  • High tensile, creep, rupture strength, outstanding fatigue and thermal-fatigue strength; oxidation resistance; and excellent weldability and braze-ability make it good choice in the aerospace industry

Chemical Composition

C CR FE NI AL TI MO CB + TA MN SI P S CO
MAX MAX MIN MAX MAX MAX MAX MAX MAX MAX
0.10 20.0 - 23.0 5.0 58.0 0.40 0.40 8.0 - 10.0 3.15 - 4.15 0.50 0.50 0.015 0.015 1.0
Inconel 600

Nickel Alloy Pipe: Inconel 625 for Extreme Conditions

Inconel 625 is a nickel-chromium-molybdenum alloy known for its outstanding resistance to oxidation, corrosion, and high temperatures. This nickel alloy is widely used in applications that require exceptional mechanical properties and resistance to extreme environmental conditions. Nickel alloy pipes made from Inconel 625 are particularly valued in industries such as chemical processing, aerospace, marine, and nuclear.

Chemical Composition

Element Content
Nickel (Ni) 58.0% minimum
Chromium (Cr) 20.0 - 23.0%
Molybdenum (Mo) 8.0 - 10.0%
Iron (Fe) 5.0% max
Niobium (Nb) 3.15 - 4.15%
Carbon (C) 0.10% max
Manganese (Mn) 0.50% max
Silicon (Si) 0.50% max
Sulfur (S) 0.015% max

Mechanical & Physical Properties

Property Value
Density 8.4 g/cm3
Melting Point 1350 °C (2460 °F)
Tensile Strength Psi – 1,35,000, MPa – 930
Yield Strength (0.2%Offset) Psi – 75,000, MPa – 517
Elongation 42.5 %

Inconel 625 Characteristic:

Inconel 625 Seamless Tubes Metallurgical structure

Inconel 625 Tubing Inonel 625 Pipe is face-centered cubic lattice structure. Dissolve out the carbon granule and instability quaternary phase, then change it to stability Ni3 (Nb,Ti) trimetric lattice around 650℃ after a long time heat preservation. nickel-chromium content will strength the mechanical performance in the state solution while suppress the plasticity

Inconel 625 Seamless Tubes Corrosion resistance

625 own a very good corrosion resistance in many media, especially with excellent resistance to pitting, crevice corrosion, intercrystalline corrosion, and erode in oxide, also good resistance to inorganic acid corrosion, such as nitric acid, phosphoric acid, sulfuric acid and hydrochloric acid. 625 can resist the alkali and organic acid corrosion in the oxidation and reduction environment. Effect resists the chloride reduction stress corrosion cracking. Normally no corrosion in the sea-water and industry environments since high corrosion resistance to the sea-water and salting liquid,as well as in high temperature, without sensitivity during welding. 625 have the resistance to oxidation and carbonizing in the static and cycle environments, also hacve the resistance the chlorine corrosion.

Typical Applications

Motorsport applications for Inconel 625 include:
